Programmer’s Guide 10-45
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-17 MEAS1 | MEAS2 Functions, 8712ES and 8714ES (1 of 2)
KEYSTROKES SCPI COMMAND
MEAS1 | MEAS2 SENS[1|2]:STAT ON; *WAI
S11 Refl Port1 SENS[1|2]:FUNC ‘XFR:S 1,1’;DET NBAN; *WAI
S21 Fwd Trans SENS[1|2]:FUNC ‘XFR:S 2,1’;DET NBAN; *WAI
S12 Rev Trans SENS[1|2]:FUNC ‘XFR:S 1,2’;DET NBAN; *WAI
S22 Refl Port2 SENS[1|2]:FUNC ‘XFR:S 2,2’;DET NBAN; *WAI
Fault Location SENS[1|2]:FUNC ‘FLOC 1,0’;DET NBAN; *WAI
SRL SENS[1|2]:FUNC ‘SRL 1,0’;DET NBAN; *WAI
Power SENS[1|2]:FUNC ‘XFR:POW 2’;DET BBAN; *WAI
Conversion Loss SENS[1|2]:FUNC ‘XFR:POW:RAT 2,0’;DET BBAN; *WAI
Detection Options (menu selection only)
Narrowband Internal (menu selection only)
A SENS[1|2]:FUNC ‘XFR:POW 1’;DET NBAN; *WAI
B SENS[1|2]:FUNC ‘XFR:POW 2’;DET NBAN; *WAI
R SENS[1|2]:FUNC ‘XFR:POW 0’;DET NBAN; *WAI
A/R SENS[1|2]:FUNC ‘XFR:S 1,1’;DET NBAN; *WAI
B/R SENS[1|2]:FUNC ‘XFR:S 2,1’;DET NBAN; *WAI
--> Path
FWD rev
ROUT[1|2]:PATH:DEF:PORT [(2,1)|(1,2)]; *WAI
