Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-18 MEAS1 | MEAS2 Functions, 8712ET and 8714ET (1 of 2)
KEYSTROKES SCPI COMMAND
MEAS1 | MEAS2, (continued)
Transmissn SENS1:FUNC ‘XFR:S 2,1’;DET NBAN; *WAI
Reflection SENS1:FUNC ‘XFR:S 1,1’;DET NBAN; *WAI
Fault Location SENS1:FUNC ‘FLOC 1,0’;DET NBAN; *WAI
SRL SENS1:FUNC ‘SRL 1,0’;DET NBAN; *WAI
Power SENS1:FUNC ‘XFR:POW 2’;DET BBAN; *WAI
Conversion Loss SENS1:FUNC ‘XFR:POW:RAT 2,0’;DET BBAN;
*WAI
Detection Options (menu selection only)
Narrowband Internal (menu selection only)
A SENS[1|2]:FUNC ‘XFR:POW 1’;DET NBAN; *WAI
B SENS[1|2]:FUNC ‘XFR:POW 2’;DET NBAN; *WAI
R SENS[1|2]:FUNC ‘XFR:POW 0’;DET NBAN; *WAI
A/R SENS[1|2]:FUNC ‘XFR:S 1,1’;DET NBAN; *WAI
B/R SENS[1|2]:FUNC ‘XFR:S 2,1’;DET NBAN; *WAI
