10-48 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-18 MEAS1 | MEAS2 Functions, 8712ET and 8714ET (2 of 2)
KEYSTROKES SCPI COMMAND
MEAS1 | MEAS2,(continued)
Broadband Internal (menu selection only)
B* SENS[1|2]:FUNC ‘XFR:POW 2’;DET BBAN; *WAI
R* SENS[1|2]:FUNC ‘XFR:POW 0’;DET BBAN; *WAI
B*/R* SENS[1|2]:FUNC ‘XFR:POW:RAT 2,0’;DET BBAN;
*WAI
Broadband External (menu selection only)
X SENS[1|2]:FUNC ‘XFR:POW 11’;DET BBAN; *WAI
Y SENS[1|2]:FUNC ‘XFR:POW 12’;DET BBAN; *WAI
X/Y SENS[1|2]:FUNC ‘XFR:POW:RAT 11,12’;DET
BBAN; *WAI
Y/X SENS[1|2]:FUNC ‘XFR:POW:RAT 12,11’;DET
BBAN; *WAI
Y/R* SENS[1|2]:FUNC ‘XFR:POW:RAT 12,0’;DET
BBAN; *WAI
Aux Input SENS[1|2]:FUNC ‘XFR:VOLT’; *WAI
Meas OFF SENS[1|2]:STAT OFF; *WAI
See Table 10-20 on page 10-49 for Multiport Test Set.
