Programmer’s Guide 10-49
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-19 MEAS Multiport Test Set Functions, 8712ES and 8714ES
Table 10-20 MEAS Multiport Test Set Functions, 8712ET and 8714ET
KEYSTROKES SCPI COMMAND
MEAS1 | MEAS2, (Multiport)
S11 ReflPort SENS1:FUNC ‘XFR:S 1,1’;DET NBAN; *WAI
S21 Tran SENS1:FUNC ‘XFR:S 2,1’;DET NBAN; *WAI
S12 Tran SENS1:FUNC ‘XFR:S 1,2’;DET NBAN; *WAI
S22 ReflPort SENS1:FUNC ‘XFR:S 2,2’;DET NBAN; *WAI
Multiport Selection (menu selection only)
(S11) Port (menu selection only)
(S22) Port (menu selection only)
KEYSTROKES SCPI COMMAND
MEAS1 | MEAS2, (Multiport)
Reflection SENS1:FUNC ‘XFR:S 1,1’;DET NBAN; *WAI
Transmissn SENS1:FUNC ‘XFR:S 2,1’;DET NBAN; *WAI
Multiport Selection (menu selection only)
Reflection Port Num ROUT[1|2]REFL:PATH:DEF:PORT[1|2|...|10]
Transmissn Port Num ROUT[1|2]TRAN:PATH:DEF:PORT[1|2|...|10]
