Programmer’s Guide 11-9
SCPI Command Summary
SCPI Device Command Summary
Table 11-2 CALCulate (5 of 7)
1. Binary parameters accept the values of 1 (on) and 0 (off) in addition to ON and OFF.
SUBSYSTEM COMMANDS FORM DESCRIPTION
CALCulate[1|2]:MARKer
:FUNCtion:RESult?
query
only
NR3
[,NR3,
NR3,
NR3]
Queries the results of the active marker
function — MAX and MIN return the
amplitude; TARG returns the frequency;
BWID returns bandwidth, center
frequency, Q and loss; STAT returns the
frequency span, the mean and standard
deviation of the amplitude response,
and the peak-to-peak ripple; FLAT
returns the frequency span, gain, slope
and flatness; and FSTAT returns the
insertion loss and peak-to-peak ripple of
the passband of a filter, as well as the
maximum signal amplitude in the
stopband. Refer to the MARKERS
example program in the Example
Programs Guide for more information.
CALCulate[1|2]:MARKer
:FUNCtion[:SELect] <char>
CHAR Selects the active marker function —
choose from
OFF|MAXimum|MINimum|TARGet
|BWIDth|NOTCh|MPEak|MNOTch
|STATistics|
FLATness|FSTATistics.
CALCulate[1|2]:MARKer
:FUNCtion:TRACking
<ON|OFF>
1
NR1 Turn marker function tracking on/off.
CALCulate[1|2]:MARKer
[1|2|8]:GDELay?
query
only
Returns the group delay value, in
seconds, at the specified marker.
CALCulate[1|2]:MARKer
[1|2|8]:MAXimum
command
only
Sets the specified marker to the
maximum value on the trace.
CALCulate[1|2]:MARKer
[1|2|8]:MAXimum:LEFT
command
only
Moves the specified marker to the next
local maximum to the left.
