Agilent APG remote start/stop cable, 03396-61010
Synchronizes the GC with an Agilent integrator. Additional cables may be used to add more
instruments (up to 10 total).
Figure 21. Remote start/stop cable, GC to Agilent integrator
Agilent APG remote start/stop cable, G1530-60930
Synchronizes the GC with another Agilent instrument. Additional cables may be used to add
more instruments (up to 10 total).
Figure 22. Remote start/stop cable, GC to Agilent instrument
