4-28
Screens
Cell Control - Active Cell
4. Bit Error This field displays the bit error or fast bit error measurements screen depending on
which mode has been set in these screens.
See Also Screens: Bit Error or Fast Bit Error
5. Call Status This field displays the status of the communication between the mobile phone and
the Agilent 8922M/S. For the active cell, the states are:
• Inactive
• Proceeding
• Alerting
• Connected
6. Channel (Base
Station)
This field selects which channel the Agilent 8922M/S transmits the Broadcast
Channel (BCCH) information. If this is changed during a call, the call will be
deactivated.
7. CW Meas This field displays the CW measurements screen.
8. dBm This field displays the units of the Peak Power measurement.
See Also Keys: ON/OFF, HI LIMIT, LO LIMIT, REF SET, AVG,
UNITS, METER
9. GSM900/E-
GSM/DCS1800/P
CS1900
This field selects the type of mobile that is to be tested.
Choices GSM 900
E-GSM
DCS 1800
PCS 1900
10. Out RF SP This field displays the output RF spectrum measurements screen.
11. Peak Power This field displays the measured peak carrier power.
NOTE The measurement display will not update if there is no signal to measure. This
includes the case where the expected input level has been set too high.
12. Phase/Frq This field displays the phase and frequency measurements screen.
To Next Page
