6-18
Connectors
Signal Descriptions for SYSTEM BUS
Signal Descriptions for SYSTEM BUS
System Bus Pin
Number Overview
Table 2-1 System Bus Connector Pin Numbers
Pin
Number
Signal Name Pin
Number
Signal Name
1 FP_DATA 20 FP_CLOCK
2 GND 21 MEAS_TRIG_OUT
3 RP_GSM_RST_IN 22 DEMOD_DATA
4 DEMOD_CLK 23 DEMOD_VALID
5 RP_GSM_RST_OUT 24 G_EXT_TRIG_OUT
6 PULSE_MOD_IN 25 GND
7 RP_DMOD_TRIG 26 RP_BURST_T1
8 RP_BURST_T2 27 RP_BURST_T3
9 SEQ_TRIG_OUT 28 RP_TX_HOP
10 RP_RX_HOP 29 RP_SEQ_HOP
11 RP_RST_SEQ_HOP 30 RP_HOP_INHIBIT
12 RP_HOP_ADRS0 31 RP_HOP_ADRS1
13 RP_HOP_ADRS2 32 RP_HOP_ADRS3
14 RP_HOP_ADRS4 33 RP_HOP_ADRS5
15 RP_HOP_ADRS6 34 RP_HOP_ADRS7
16 RP_HOP_ADRS8 35 RP_HOP_ADRS9
17 RP_HOP_ADRS20 36 GND
18 RP_RXD 37 RP_TXD
19 GND
