Agilent Technologies 8922M User Manual

2-13
Making Measurements
Measurements
Measurements
The measurements available on the Agilent 8922M/S can all be accessed from the
cell control screen by selecting a measurement field under MEASUREMENTS,
(see Figure 2-5 on page 2-13) and pushing the knob.
GSM Specific
Measurements
The measurements available are:
• Peak Carrier Power
• Phase and Frequency Error
• Power Ramp Mask
• Bit Error Rate
• Output RF Spectrum (modulation or ramping, Option 006 only)
Ancillary
Measurements
You can also use the toolkit capabilities of the Agilent 8922M/S. These additional
measurements are:
• Spectrum Analyzer (Option 006 only)
• Scope
• Audio Measurements
• CW Measurements
Figure 2-5 Agilent 8922M/S Measurements
GSM Specific Measurements
Ancillary Measurements
