4-53
Screens
Configure
17. RF Level Offset This field enables/disables the effects of the RF In/Out, Aux RF Out, and Aux
RF In fields below it.
• When set to On, the RF Generator amplitude and RF Analyzer power
measurement are offset by the values entered in these fields.
• When set to Off, the values in these fields are ignored.
See Also Aux RF In Aux RF Out RF In/Out
18. Screen Freeze This field enables/disables screen updating. The default setting is screen updating
OFF. When enabled, all keys and control knob are still active.
The primary use of this field is for GPIB control. When this field is returned to ON,
the screen returns to the state it was in when measurements were being made.
Screen freezing is used to enhance speed improvements.
19. SERVICE This field in the To Screen list is only present on the Configure screen. It allows
access to the Service screen.
20. Time This field sets the internal instrument clock.
