4-62
Screens
I/O Configuration
18. Rcv Pace This field is used to select if data will be paced through the serial port.
Choices None disables the Xon/Xoff function
Xon/Xoff sets ASCII control codes Xon and Xoff to either start or
stop data transmission from the computer to the instrument.
19. Serial Baud This field sets the baud rate for serial port.
Choices 300
600
1200
2400
4800
9600
19200
20. Serial In This field configures the serial port (Inst) communication to the serial input port or
IBASIC control of the serial input port.
• Inst configures the serial port to connect to an external ASCII RS-232 terminal
or computer.
• IBASIC allows the IBASIC controller to read the serial port.
21. Stop Length This field sets the number of stop bits used for serial communication.
Choices 1 bits
1.5 bits
2 bits
22. Xmt Pace This field is used to select if data will be paced through the serial port.
Choices None disables the Xon/Xoff function.
Xon/Xoff sets ASCII control codes Xon and Xoff to either start or
stop the instrument from transmitting to the computer.
