4-76
Screens
Oscilloscope, Main Controls
2. Controls This field selects the set of oscilloscope controls.
Choices Main
Trigger
Marker
3. Marker This field displays the signal level at the current marker position. The units-of-
measure for this field are determined by the AF Anl In selection.
See Also Keys: ON/OFF, HI LIMIT, LO LIMIT, REF SET, AVG, Units
4. Meas Reset Selecting Meas Reset will erase any accumulated measurements used for calculating
a final result, and re-start the measurement process for the following functions:
• HI LIMIT
• LO LIMIT
• AVG
See Also Keys: HI LIMIT, LO LIMIT, AVG
5. Time/div This field selects the horizontal sweep time per division.
Choices 200, 100, 50, 20, 10, 5, 2, or 1 ms
500, 200, 100, 50, 20, 10, 5, 2, or 1 µs
6. Vert/div This field, vertical sensitivity, sets the vertical amplitude per division. The units-of-
measure for this field are determined by the AF Anl In selection. When selecting
upper or lower limits of vertical sensitivity, an UNCAL message appears on the
display. This message indicates that the scope is operating out with calibrated
ranges.
See Also Screens: Audio, (AF Anl In)
7. Vert Offset This field moves the displayed signal trace above or below the oscilloscope’s fixed
centerline.
