4-87
Screens
Phase and Frequency Error - Multiburst OFF
3. ON/OFF This field enables or disables multi-burst measurement. The default for this field is
OFF.
Choices ON enables multi-burst measurement. The display changes to
show Bursts measured fields; Wanted, Done, and Errors.
OFF disables multi-burst measurement.
See Also Screens: Phase and Frequency Error - Multi-burst ON
4. Peak Phase Error This field displays the measured Peak Phase Error over the useful bits in the
measured burst.
See Also Keys: ON/OFF, HI LIMIT, LO LIMIT, REF SET, AVG,
METER, Units
5. RMS Phase Error This field displays the measured RMS Phase Error over the useful bits in the
measured burst.
See Also Keys: ON/OFF, HI LIMIT, LO LIMIT, REF SET, AVG,
METER
6. Single/Cont Single allows one test to be performed. Cont allows testing to automatically repeat.
7. Sync Status This field displays any errors that occurred while trying to synchronize to the
demodulated data.
See Also Making Measurements: Solving Problems Messages
8. Trig Delay This field sets the time delay between a valid trigger event and the beginning of a
measurement.
Range 0 to 5000.00 µs.
9. View This field selects alternate views of the measurement.
Choices Phase Err
Data Bits
