4-90
Screens
Phase and Frequency Error - Multi-burst ON
8. Sync Status This field displays any errors that occurred while trying to synchronize to the
demodulated data.
See Also Making Measurements: Solving Problems Messages
9. Trig Delay This field sets the time delay between a valid trigger event and the beginning of a
measurement.
Range 0 to 5000.00 µs.
10. View This field selects alternate views of the measurement.
NOTE Selecting any of these alternate views, displays information relating to the Last
Burst Only.
Choices Phase Err
Data Bits
11. Wanted This field defines the number of bursts to be measured during a measurement cycle.
The default value is 10.
Range 1 to 999
