Agilent Technologies 8922M User Manual

4-108
Screens
Pwr Ramp: Pulse Rise (Option 006 Only)
4. POnOffRise This field displays the measured amplitude at the rise-position time relative to the
average On power over the useful bits in the measured burst.
See Also Keys: ON/OFF, HI LIMIT, LO LIMIT, REF SET, Units
5. SyncStatus This field displays any errors that occurred while trying to synchronize to the
demodulated data.
See Also Making Measurements: Solving Problems Messages
6. Trig Delay This field sets the time delay between a valid trigger event and the beginning of a
measurement.
Range 0 to 5000.00 µs
7. View This field selects the alternate Views of the Pulse On/Off Ratio measurement.
Choices Rise Edge
Top 2 dB
Fall Edge
Summary
