4-110
Screens
Pwr Ramp: Pulse Fall (Option 006 Only)
3. MarkerPos This field selects the marker position for the rising trace.
Choices MarkerPos
Fall Pos
Range 0.0 to +56.0 µs
4. POnOffFall This field displays the measured amplitude at the fall-position time relative to the
average On power over the useful bits in the measured burst.
5. SyncStatus This field displays any errors that occurred while trying to synchronize to the
demodulated data.
See Also Making Measurements: Solving Problems Messages
6. Trig Delay This field sets the time delay between a valid trigger event and the beginning of a
measurement.
Range 0 to 5000.00 µs
7. View This field selects the alternate Views of the Pulse On/Off Ratio measurement.
Choices Rise Edge
Top 2 dB
Fall Edge
Summary
