5-9
Keys
Function Keys
28. RFG/RFA This key is used to access the RF Generator/RF Analyzer screen, and gain direct
control over the internal source and receiver.
NOTE The changes to settings on this screen may affect the operation of the Cell Control
screen. Pressing will ensure that the instrument returns to a known state.
See Also
Screens: RF Generator / RF Analyzer
29. SAVE This key is used to save instrument setups to be recalled later.
Changes made on the Configure and Tests screens are automatically maintained
through power-down and Preset cycles.
Help, Message, and Tests screens cannot be saved. The states of the following fields
will not be saved: Demod Arm, Hop Arm, Activated, Meas Arm.
To Save an Instrument Setup
1 Make any changes to the instrument that you want to SAVE.
2 Press , to save.
3 Name the setup using the data keys, or the Save choices at the bottom right of the
screen. (You can use numbers, letters, or a combination of both.)
30. TESTS This key is used to access the Tests screen. This is where the IBASIC Test Software
Applications can be run from. Refer to chapter 8, Instrument BASIC for more
information.
31. USE MEM This key arms and triggers a DSP measurement using data captured in memory.
USE MEM is not available when continuous measurements are selected. Select
single in the MEAS SYNC screen to allow this operation.
See Also
Screens: Measurement Sync [Trig Source (Use Mem), Status (Use
Mem)] Screens: Measurement Sync (Status), [Single/Cont (Meas Trig)] Screens:
Cell Configuration
32. YES This key is used to respond to Yes/No questions that appear on the screen.
PRESET
SHIFT RECALL
