Agilent Technologies 8922M User Manual

6-5
Connectors
Front-Panel Connectors of the Agilent Technologies 8922M/S
8. IN HI (AUDIO) The input high connector is connected to the audio analyzer input. This connector is
used as the main (external) audio analyzer input connection (when selected). This
connector is also used in combination with the audio input low signal to input a
floating input signal (for better noise performance) to the audio analyzer.
See Also Screens: Audio (Audio In Lo)
9. IN LO (AUDIO) The input low connector is connected to the audio analyzer input. This connector is
the main (external) audio analyzer input connection (when selected, and in FLOAT
mode).
This connector is used in combination with the audio input, high signal to input a
floating input signal (for better noise performance) to the audio analyzer.
See Also Screens: Audio (Audio In Lo)
