Agilent Technologies 8922M User Manual

3-15
Verifying Performance
Agilent Technologies 8922M/S Specifications
Output
Supplemental Characteristics:
Frequency Overrange
To 1015 MHz with uncalibrated output and modulation
Switching Speed
577 µs over the GSM frequency bands in hop mode (refer to 0.3
GMSK modulation specs
RF In/Out Connector
Level Range
−14 to −127 dBm
Level Resolution
0.1 dB
Level Accuracy
2
GSM Bands
1
±1.0 dB, levels ≥−127dBm,
maximum over range >
−12 dB ±1.0 dB,
typically for levels
≥−127 dBm while hopping.
50 MHz to 1 GHz
±1.5 dB, levels ≥−107 dBm
±2.0 dB, levels ≥−127 dBm
10 MHz to 50 MHz
±2.0 dB, levels ≥−107 dBm
±2.5 dB, levels ≥−127 dBm
Reverse Power
15 Watts continuous
100 Watts for 10 seconds/minute
SWR
1.5:1
Aux RF Out Connector
Level Range +4 to
−127 dBm
Level Resolution
0.1 dB
Level Accuracy
2
GSM Bands
1
±1.0 dB, levels ≥−107 dBm
±1.0 dB, typically for levels≥−107 dBm while hopping.
50 MHz to 1 GHz
±1.5 dB, levels ≥−107 dBm
±2.0 dB, levels ≥−127 dBm
10 MHz to 50 MHz
±2.0 dB, levels ≥−107 dBm
±2.5 dB, levels ≥−127 dBm
Reverse Power
200 milliwatts
SWR 2.0:1, level <
−4 dBm
1. GSM frequency bands are 880 to 915 MHz and 925 to 960 Mhz.
2. Level accuracy degrades 0.2 dB when using the RF in/out connector for both RF generator and RF analyzer. In 30dB
pulse mode, level accuracy specifications are typical.
