Agilent Technologies 8922M User Manual

3-22
Verifying Performance
Agilent Technologies 8922M/S Specifications
FM Demodulation Output (Agilent 8922M only)
Pulse Demodulation Output (Agilent 8922M only)
Range
RF In/Out
−6 to +41 dBm
Aux RF In
−36 to +20 dBm
Sensitivity
20µV/Hz
±5% (into an open circuit)
Input Frequency Setting Error
±50 kHz, with ≤100 kHz pk deviation
Input Level Setting Error
±3 dB
Supplemental Characteristics
3 dB Bandwidth
DC to 270 kHz
Output Impedance
600 Ω
DC Offset
≤5 mV
Range
RF In/Out
−6 to +41 dBm
Aux RF In
−36 to +20 dBm
Input Frequency Setting Error
±50 kHz
Input Level Setting Error
±3 dB
Rise Time (10 to 90%)
≤2.5 µs
Fall Time (90 to 10%)
≤2.5 µs
Supplemental Characteristics:
Output Impedance
600 Ω, DC Coupled
Output Level
2 Vpk into an open circuit
