3-24
Verifying Performance
Agilent Technologies 8922M/S Specifications
Spectrum Analyzer
Specifications
(Option 006)
Frequency Range 10 MHz to 1 GHz
Frequency Span/Resolution
Bandwidth (coupled)
Span Bandwidth
<50 kHz 300 Hz
<200 kHz 1 kHz
<1.5 MHz 3 kHz
≤4 MHz
30 kHz
Display Log, 10 dB/div
Display Range 80 dB
Log Linearity
±1.1 dB
Reference Level
RF In/Out +44 to
−24 dBm
Aux RF In +23 to
−55 dBm
Non-harmonic Spurious
Responses
−50 dBc max, for inputs ≤30 dBm
Residual Responses
<
−70 dBm (no input signal, 0 dB attenuation)
Image Rejection >50 dB
Supplemental Characteristics:
Level Accuracy
±2.5 dB
Frequency Overrange
To 1015 MHz
Displayed Average Noise Level <
−116 dBm (0 dB attenuation, <50 kHz spans).
