APPLy Subsystem

Commands and Queries

APPLy?

APPLy:ARBitrary

APPLy:DC

APPLy:NOISe

APPLy:PRBS

APPLy:PULSe

APPLy:RAMP

APPLy:SINusoid

APPLy:SQUare

APPLy:TRIangle

[SOURce[1|2]:]APPLy?

Queries the output configuration.

Parameter Typical Return

(none) "SIN +5.000000000000000E+03,

+3.0000000000000E+00,

-2.5000000000000E+00"

Return the configuration for a 5 kHz, 3 V sine wave with a -2.5 VDC offset.

APPLY?

l The function, frequency, amplitude, and offset are returned as shown above. The amplitude, but not the offset, is

returned as specified by VOLTage:UNIT.

[SOURce[1|2]:]APPLy:ARBitrary [{<sample_rate>|MIN|MAX|DEF}

[,{<amplitude>|MIN|MAX|DEF} [,{<offset>|MIN|MAX|DEF}]]]

Outputs arbitrary waveform selected by FUNCtion: ARBitrary, using the specified sample rate, amplitude, and offset.

Parameter Typical Return

<sample_rate> from 1 µSa/s to 250 MSa/s, default 40 kSa/s (none)

<amplitude> from 1 mVpp to 10 Vpp into 50 Ω, 2 mVpp to 20 Vpp into an open circuit,

default 100 mVpp into 50 Ω

<offset> is the DC offset voltage (default 0), from ±5 VDC into 50 Ω, or from ±10 VDC

into an open circuit.

Output the arbitrary waveform selected using FUNCtion:ARBitrary:

APPLy:ARBitrary 1 KHZ, 5.0, -2.5 V

General

164 Agilent 33500 Series Operating and Service Guide
