2-14 Chapter2
Getting Started
Display Annotation
Table 2-3 Screen Annotation
Item Description Function Key
1 Detector mode Detector
2 Reference level Ref Level
3 Active function block Refer to the description of the
activated function.
4 Screen title Change Title
5 Time and date display Time/Date On Off
6 RF attenuation Attenuation Auto Man
7 Marker frequency Marker Count On Off
8 Marker amplitude Marker
9 GPIB annunciators See Table 2-7 on page 2-17 for
more information.
10 Data invalid indicator Sweep (Single) or View/Trace
11 Status Informational
messages
See Chapter 4 ,“Troubleshooting.”
12 Key menu title Dependent on key selection.
13 Key menu See key label descriptions in
Chapter 6 ,“Front-Panel Key
Reference.”
14 Frequency span or stop
frequency
Span or Stop Freq
15 Sweep time/Points Sweep Time Auto Man, Sweep
Points
16 Video bandwidth Video BW Auto Man
17 Frequency offset Freq Offset
18 Display status line Displays instrument status and
error messages. Cleared by
pressing Esc key.
See Chapter 4 ,“Troubleshooting.”
19 Resolution bandwidth Resolution BW Auto Man
20 Center frequency or start
frequency
Center Freq or Start Freq
21 Auto alignment routine
is on
Auto Align
See below for more information.
