2-2
Assembly Replacement
Before You Replace an Assembly
Before You Replace an Assembly
CAUTION Many of the assemblies in this instrument are very susceptible to damage from
electrostatic discharge (ESD). Perform service procedures only at a static-safe
workstation and wear a grounding strap.
Be sure to review the warning and caution statements described in Chapter 5, "Safety and
Regulatory," on page 5-1, prior to replacing an assembly in your signal generator.
After Replacing or Repairing an Assembly
After you have replaced or repaired an assembly, certain performance tests and adjustments may
have to be performed. Please refer to Chapter 4, "Post-Repair Procedures," on page 5-1, for the list of
performance tests and adjustments required for each assembly.
To Next Page
