3-46

Replaceable Parts

Assemblies and Hardware Options

Outer and Inner Instrument Covers and Associated Parts

Table 3-15 Outer and Inner Instrument Covers and Associated Parts

Item No. Description Qty Part Number

1 Assy-Strap Handle - includes the following parts: 1 E8251-60067

Strap Assembly 1

Ground Spring 2

Handle Retainer 2

End Cap 2

Screw-Machine M5 x 18 FL-TX 2

2 Rear Feet Screws 4 0515-1619

3 Rear-Panel Feet 4 5041-9611

4 Feet-Bottom 4 5041-9167

5 Tilt Stand 2 1460-1345

6 Outside Instrument Cover 1 E8251-00012
