3-44
Replaceable Parts
Assemblies and Hardware Options
Type-N RF Output Connector (Option 1ED Models Only)
Figure 3-26 Type-N RF Output Connector (Option 1ED Models Only)
Table 3-13 Type-N RF Output Connector (Option 1ED Models Only)
Item No. Description Qty Part Number
1 Adapter-Type-N (f) 1 08559-60002
2 Spacer 1 E8251-20067
3 Adapter Bracket 1 E8251-00216
4 Screw-Machine M4.0 x 10 FL-TX 1 0515-1035
5 Washer lock 1 2190-0102
6 Nut-Hex 1 2950-0132
W25 Semi-Rigid Cable (refer to Table 3-1 on page 3-19.)
