Agilent Technologies E8257C User Manual

3-19
Replaceable Parts
Frequency, Hardware, and Personality Options
Cables
This section lists part numbers for the cables in your signal generator.
Table 3-1
Reference
Designator
Input Output Part Number
A1W1
*
Ribbon Cable, A1 Keyboard A31P13 (part of A1)
A2DS1W1
*
Wire Cable, A2DS1 A4 Inverter (part of A2)
A4W1
*
Wire Cable, A4 Inverter A31P12 (part of A4)
A22W1
*
A22 Line Module A19 Power Supply (part of A22)
A22W2
*
A22 Line Module chassis ground post on rear
panel and A19 Power
Supply
(part of A22)
A25BW1
*
Wire Cable, A25B Highband
Detector Bias board
A26J12 (part of A25)
A32W1
*
Wire Cable, A32 10 MHz
Crystal Oscillator
A21P2 (part of A32)
B1W1
*
Wire Cable, B1 Fan A21P251 (part of B1)
W1 EXT 1 of front panel A11J401 8121-0628
W2 EXT 2 of front panel A11J402 8121-0628
W3 LF OUTPUT of front panel A11J403 8121-0628
W4 ALC INPUT of front panel A10J4 8121-0859
W5 PULSE/TRIGGER GATE
INPUT of front panel
A11J201 8121-0625
W6 PULSE VIDEO OUT of front
panel
A11J203 8121-0625
W7 PULSE SYNC OUT of front
panel
A11J202 8121-0625
W8 A3 Power Switch (DATA
CABLE)
A2 Display 8121-0165
W9 A3P1 A31P11 8121-0614
W10 A9J3 A31J1031 8121-0624
W11 A9J4 A31J1021 8121-0624
W12 A9J5 A28J1 8121-0608
