Agilent Technologies E8257C User Manual

3-20
Replaceable Parts
Assemblies and Hardware Options
W13 A10J201 A30J6 8121-0624
W14 A10J5 A23J104 8121-0627
W15
(Option 540)
A10J3 A25 40 GHz Highband
Detector
8121-0607
W16 A11J204 A12 Pulse Modulator Board 8121-0623
W17 A11J205 A30J7 8121-0626
W18 A18J1 A21J3 8121-0617
W19 A18J2 A26J30 8121-0619
W20 A20J1 A26J20 8121-0677
W21 A31J1043 rear panel (10MHz OUT) 8121-0622
W22 A31J1042 rear panel (10MHz IN) 8121-0622
W23 A21J2 A31P241 8121-0611
W24
(Option 540)
Semi-Rigid Cable, A24
40 GHz Highband Coupler
output
AT1 115 dB Mechanical
Attenuator (Option 1E1)
E8251-20025
W25
(Option 540)
Semi-Rigid Cable, AT1
output
2.4 mm RF Output adapter
Option 1E1
E8251-20028
W26
(Option 540)
Semi-Rigid Cable, A24
40 GHz Highband Coupler
2.4mm RF Output adapter
(models without
Option 1E1)
E8251-20035
W27 A23J2 A30J3 E8251-20031
W28 A23J100 A26J15 8121-0616
W29
(Option 540)
A27J10 A26J33 8121-0613
W30
(Option 540)
A27J2 A24 Highband Coupler
input
E8251-20024
W31
(Option 540)
A27J3 o A30J2 E8251-20023
W32
(Option 540)
A27J1 A30J4 E8251-20022
W33 A26J32 A29J10 8121-0613
W34 A26J31 A30J10 8121-0613
W35 A26J10 A31P201 8121-0615
Table 3-1
Reference
Designator
Input Output Part Number
