Replaceable Parts
Frequency, Hardware, and Personality Options
W75 Semi-Rigid Cable, A23
Lowband Coupler/Detector
A12 Pulse Modulator Board E8251-20033
W76 Semi-Rigid Cable, A12 Pulse
Modulator Board
A31 Motherboard (Output) E8251-20032
W77
(E8267C)
A29J2 A13 I/Q MUX E8251-20018
W78
(E8267C)
A30J1 A13 I/Q MUX E8251-20019
W79
(E8267C)
A13J107 rear panel (WIDEBAND Q
INPUT)
8121-0628
W80
(E8267C)
A13J106 rear panel (WIDEBAND I
INPUT)
8121-0628
W81
(Option 520)
A10J3 A25 20 GHz Highband
Detector
8121-0900
W82
(Option 520)
A10J3 A25 20 GHz Highband
Detector
8121-0900
W83
(Option 1EM)
A27J2 A24 Highband
Coupler input
E8251-20070
W84
(Option 1EM)
Semi-Rigid Cable, A24
40 GHz Highband Coupler
output
AT1 115 dB Mechanical
Attenuator (Option 1E1)
input
E8251-20071
W85
(Option 1EM)
Semi-Rigid Cable, AT1 115
dB Mechanical Attenuator
2.4mm RF Output adapter
(RF OUT)
E8251-20072
W86
(Option 520)
Semi-Rigid Cable, AT1
output
3.5 mm or Type-N RF
Output adapter
E8251-20027
W87
(Option 1EM)
(Option 540)
Semi-Rigid, A24 40 GHz
Highband Coupler in
RF Output adapter (models
without Option 1E1)
E8251-20092
W88
(Option 1EM)
(Option 520)
Semi-Rigid, A24 20 GHz
Highband Coupler in
RF Output adapter (models
without Option 1E1)
E8251-20096
W89
(Option 520)
Semi-Rigid Cable, A24
20 GHz Highband Coupler
3.5mm RF Output adapter
(models without
Option 1E1)
E8251-20034
W90
(E8267C)
A14J21 A17P1 8121-0690
*. This cable is not replaceable by itself. You must order the corresponding assembly.
Table 3-1
Reference
Designator
Input Output Part Number
