2 Making Measurements
Measuring AC Voltage
32 U1231A/U1232A/U1233A User’s Guide
Measuring AC Voltage
Set up your multimeter to measure AC voltage as shown in
Figure 2- 2. Probe the test points and read the display.
Figure 2-1 AC voltage display
AC voltage measurements measured with this multimeter are returned as
true rms (root mean square) readings. These readings are accurate for sine
waves and other waveforms (with no DC offset) such as square waves,
triangle waves, and staircase waves.
Press to measure the frequency of the AC voltage source. See
“Measuring Frequency” on page 62 to learn more.
