Agilent Technologies U1231A - Figure 2-10 Continuity Test Flow

2 Making Measurements
Testing for Continuity
42 U1231A/U1232A/U1233A User’s Guide
Figure 2-10 Continuity test flow
NOTE
Open continuity is disabled by default
The open continuity test option must be enabled in the Setup menu before
it can be selected via the key. See “Enable open continuity test by
default” on page 99 to learn more.
S
h
i
f
t
E
s
c
the open continuity test
S
h
i
f
t
E
s
c
Pr e ss t o sw it ch t o
the short continuity test
S
h
i
f
t
E
s
c
Pr e ss t o sw it ch t o
the resistance measurement
S
h
i
f
t
E
s
c
Press to switch to
Short detected,
beeper sounds
Open detected,
beeper sounds
Circuit open
Ci r c u i t
complete
