2 Making Measurements
Measuring Temperature
54 U1231A/U1232A/U1233A User’s Guide
Figure 2-20 Using the Auxillary Temperature measurement function
(Only applicable for the U1231A and U1232A models)
3
1
2
Plug the sensor
into the adapter
Ambient temperature
AUX
Plug the adapter
into the terminal
