Chapter 5: Maintenance and Troubleshooting
VSpin User Guide
To lock the door:
1. Click the
Diagnostics tab at the top of the VSpin Control dialog box.
The
Diagnostics page opens.
2. Click
Lock door in the Door Lock Actuator group box.
The door locks, and cannot be opened without sending an unlock
command or unlocking it manually.
To unlock the door:
1. Click
Unlock door in the Door Lock Actuator group box.
The door unlocks.
Opening and Closing
the Door
!! INJURY HAZARD !! When the door closes, it applies
10 pounds of force to any object that obstructs its movement.
This is not enough to break a finger for instance, but it could
cause abrasions or bruising.
You can command the door to open or close, unless the VSpin is
spinning.
The door must be closed before you can start a spin.
The door will not open until it is unlocked.
To open the door:
1. Click the
Diagnostics tab at the top of the VSpin Control dialog box.
The
Diagnostics page opens.
2. Verify that the door is unlocked by checking the
Door locked status
lights on the
Control or Diagnostics pages.
3. Click
Open door in the Door Open Actuator group box.
The door opens.
To close the door:
1. Click
Close door in the Door Open Actuator group box.
The door closes.
!! INJURY HAZARD !! Keep hands clear of door during
closing.
