Chapter 5: Maintenance and Troubleshooting
VSpin User Guide
84
4. Place the VSpin into the pink anti-static bag.
5. Pack the buckets into the bucket box:
a. Pack each of the buckets in their foam-wrap material, and place
them into the bucket box.
b. Put an additional piece of foam-wrap material between the
buckets to keep them from moving during shipment.
6. Place the VSpin packing contents into the VSpin shipping box using
the following diagram as a guide:
a. Place the piece of spacer foam into the box first.
b. Place the bottom piece of foam into the box second.
c. Place the VSpin into the bottom foam piece.
d. Securely place the top pice of foam over the VSpin.
7. Place the bucket box under the hinged piece of the top packing
foam.
00146
VSpin
door foam
VSpin
00146
Foam insert
00145
VSpin
packing sandwitch
00145
Top piece of foam
VSpin (anti-static bag
not shown)
Bottom piece of foam
Spacer foam
