Vehicle size parameters
Item Value
Overall dimension
Length (mm) 4680
Width (mm)
1865 (without exterior rearview
mirror)
Height (mm) 1700 (with shark fin antenna)
Wheel track
Front wheel track (mm) 1592
Rear wheel track (mm) 1590
Wheel base (mm) 2800
Front suspension (mm) 910
Rear suspension (mm) 970
Power battery parameters
Item Value
Product model MAS861 MAS8611
Power battery model AIBP-LFCE-002 AIBP-LFXE-001 / AIBP-LFCE-003
Type of power battery Ternary lithium ion battery
Rated capacity (kWh) 63
Weight (kg) 359 365
Rated Voltage(V) 347 350/351
Protection level IP67
AIWAYS U5 | 207
