Aiways U5 2021 - Sitting Adjustment Guidelines

Sitting adjustment
Seat positions
Adhere to the following details for front/rear seat positions and backrest angles:
NOTE: The seat front/rear positions are expressed by the H-point position (the H-point is the connection
point between your torso and the thigh, i.e. the crotch point).The data in the table are measured under
no-load condition.
Position //
// Item
Front seat Rear seat
left right left right
A（mm） 1368 1368 2292 2292
B（mm） 365 365 360 360
C（mm） 350 350 370 370
α（°） 25 25 27 27
54 | AIWAYS U5
