Version 1.21 117
s5000
/
s6000
EDIT PROGRAM
PEAK 1
A peak filter with a single peak that can be used to
emphasise a band of frequencies much like a single
band of EQ. Resonance increases the intensity of
the peak.
PEAK 2
A peak filter with a two peaks spaced two octaves
apart. Resonance increases the intensity of the
peaks.
PEAK 3
A peak filter with a two peaks spaced three octaves
apart. Resonance increases the intensity of the
peaks.
WIDE PEAK
Another dual peak filter with one peak in the upper
frequencies and the other in the lower frequencies.
BI-PEAK A dual peak filter based on PEAK 1 in which
modulation sweeps the peaks in opposite directions
- as one moves up through the frequency range, the
other moves down and
vice versa
.
NOTE: The differences between the five peak filters are subtle, it must be said but with different
cutoff frequency and resonance settings and depending on the modulation settings and the
sound being processed, you will hear quite distinct differences.
