46 Version 1.21
MULTI
s5000
/
s6000
EFFECTS SEND This sets the effects send level of the part.
NOTE: On the S5000, the EB20 effects processor needs to be installed.
FINE TUNE This allows you to tune the part +/-50 ‘cents’ or +/-1 semitone.
MIDI CHANNEL This allows you to set the selected part’s MIDI channel. You may set 1-
16A and 1-16B.
Those, then, are the key parameters for the parts. To edit them, simply select the part you want to
edit, then select the parameter and turn the DATA wheel.
TIP: Once you have selected a parameter to edit, you can use the SCROLL UP/DOWN keys
to set the same parameter for other parts.
For example, to set the levels of parts, select one part, select (and set) the LEVEL parameter
and then use the SCROLL keys to set LEVEL for the other parts. In this way, you don’t have to
keep jumping between the soft keys on the left and those on the right of the screen.
