ALE M3-M5-M7-M8 DeskPhones Administrator Guide
16
Description
It enables or disables the LLDP (Linker Layer Discovery Protocol) feature on the IP
phone.
Permitted
Values
true - enable
false - disable
Default
true
Web UI
Network → LLDP → VLAN Acquirement
Phone UI
Menu → Advanced Setting (default password: 123456) → Network → LLDP → VLAN
Acquirement
2.4.2 Manual VLAN Configuration
VLAN is disabled on IP phones by default. You can configure VLAN for the Internet port and PC port
manually. Before configuring VLAN on the IP phone, you need to obtain the VLAN ID from your network
administrator.
The following table lists the parameters you can use to configure VLAN manually.
Parameter
DeviceNetworkLanVlanEnable
config.xml
Description
It enables or disables the VLAN for the Internet port.
Permitted
Values
true - enable
false - disable
Default
false
Web UI
Network → IP Parameters → LAN VLAN
Phone UI
Menu → Advanced Setting (default password: 123456) → Network → IP Config → Vlan
→ Vlan Config → Use VLAN
Parameter
DeviceNetworkLanVlanNumber
config.xml
Description
It configures the VLAN ID for the Internet port.
Note: It works only if “DeviceNetworkLanVlanEnable” is set to true.
Permitted
Values
Integer from 0 to 4095
Default
4095
Web UI
Network → IP Parameters → LAN VLAN Number
Phone UI
Menu → Advanced Setting (default password: 123456) → Network → IP Config → Vlan
→ Vlan Config → ID
Parameter
DeviceNetworkPcVlanEnable
config.xml
Description
It enables or disables the VLAN for the PC port.
Permitted
Values
true - enable
false - disable
Default
false
Web UI
Network → IP Parameters → PC VLAN
Phone UI
Menu → Advanced Setting (default password: 123456) → Network → IP Config → Vlan
→ Data Vlan Config → Use VLAN
