Chapter 2 Plan the Kinetix 6000 Drive System Installation
In this example, the enclosure must have an exterior surface of 6.66 m
2
. If any
portion of the enclosure is not able to transfer heat, do not include that portion
in the calculation.
Because the minimum cabinet depth to house the 460V drive (selected for this
example) is 302 mm (11.9 in.), then the cabinet needs to be approximately
2500 mm (high) x 950 mm (wide) x 302 mm (deep).
2 x (0.3 x 0.95) + 2 x (0.3 x 2.5) + 2 x (0.95 x 2.5) = 6.82 m
2
Because this cabinet size is considerably larger than what is necessary to house
the system components, consider some means of cooling in a smaller cabinet to
be more efficient. Contact your cabinet manufacturer for options available to
cool your cabinet.
Table 12 - Power Dissipation Specifications
Bulletin 2094 Drive Modules
(1)
Usage as % of Rated Power Output
(watts)
20% 40% 60% 80% 100%
IAM (converter) module
(2)
2094-AC05-MP5-S 8 11 15 19 24
2094-AC05-M01-S 9 12 16 20 25
2094-AC09-M02-S 1420283646
2094-AC16-M03-S 1930435874
2094-AC32-M05-S 41 68 100 136 176
2094-BC01-MP5-S
18 21 25 29
34
2094-BC01-M01-S 33
2094-BC02-M02-S 3644546475
2094-BC04-M03-S 50 67 87 110 135
2094-BC07-M05-SS 71 101 137 179 226
IAM (inverter) module or AM module
(2)
2094-AC05-MP5-S or 2094-AMP5-S 28 32 37 41 46
2094-AC05-M01-S or 2094-AM01-S 31 38 46 54 62
2094-AC09-M02-S or 2094-AM02-S 34 45 57 70 84
2094-AC16-M03-S or 2094-AM03-S 48 68 91 116 144
2094-AC32-M05-S or 2094-AM05-S 104 156 212 274 342
2094-BC01-MP5-S or 2094-BMP5-S 46 54 61 69 77
2094-BC01-M01-S or 2094-BM01-S 57 73 90 108 126
2094-BC02-M02-S or 2094-BM02-S 53 72 93 116 142
2094-BC04-M03-S or 2094-BM03-S 94 130 169 211 255
2094-BC07-M05-S or 2094-BM05-S 121 183 252 326 407
Shunt module - 2094-BSP2 68 121 174 227 280
IPIM module - 2094-SEPM-B24-S
To calculate power dissipation for IPIM modules on your 2094 power rail, refer to the Kinetix 6000M Integrated Drive-Motor
User Manual, publication 2094-UM003
.
(1) Power dissipation for the Bulletin 2094 control modules, catalog numbers 2094-SE02F-M00-Sx and 2094-EN02D-M01-Sx, is included in the IAM and AM power module specifications.
(2) Internal shunt power is not included in the calculations and must be added based on utilization.
