94 Rockwell Automation Publication 2094-UM001J-EN-P - March 2017

Chapter 5 Connect the Kinetix 6000 Drive System

Figure 46 - Setting the Ground Jumper (460V Series B and C IAM modules)

P16

P17

P18

P19

(behind P18)

P18

P19

Bottom Screw

Front Panel (opened)

Ground jumper set

for grounded configuration

(default setting).

Ground jumper set for

ungrounded configuration.

Top Screw

2094-BC01-MP5-S,

2094-BC01-M01-S,

2094-BC02-M02-S,

2094-BC04-M03-S, or

2094-BC07-M05-S

IAM Module (460V)
