Allen-Bradley PLC-5 User Manual

Publication 1785-UM012D-EN-P - July 2005
Cable Reference G-7
Cable Adapter - 1784-CP8 Connects a Workstation Using a 1784-KT, -KT2, or -KL
Card to a Permanent DH+ Networ
k
Cable - 1784-CP10
Connects Workstation to Controller Using Serial Port
1
2
3
33
34
35
36
37
60
61
62
19816
1770-CD
Twinax Cable
3-position
terminal connector
Blue
Shield
Clear
62-position
sub-miniature
connector
2
SH
1
2
SH
1
Workstation (front)
Network (back)
3-position
terminal connector
62-position
sub-miniature
connector
9-pin D-Shell
Female
25-pin D-Shell
PLC-5 Controller
Male
14
25
1
13
6
9
1
5
3.2m
(10 ft)
RXD
GND
TXD
DTR
DSR
RTS
CTS
RTS
CTS
DSR
DCD
DTR
19870
2
5
3
4
6
7
8
2
7
3
4
5
6
8
20

Allen-Bradley PLC-5 Specifications

General

Programming Software	RSLogix 5
Programming Languages	Ladder Logic
Power Supply	120/240V AC or 24V DC
Communication Ports	DH+, Remote I/O, Ethernet/IP, ControlNet
Operating Temperature	0 to 60°C (32 to 140°F)
Relative Humidity	5 to 95% non-condensing
Memory	Up to 64K words (user program and data)
