Publication 1747-RM001G-EN-P - November 2008
SLC Status File B-31
Table B.3 S:6 Error Codes
Address Error
Code
(Hex)
User Program Instruction
Errors
Fault Classification Processor
Non-
User
User Fixed
5/01
5/02 5/03 5/04 5/05
Non-
Recov
Recov
S:6
continued
0030 Attempt was made to jump to
one too many nested subroutine
files. This code can also mean
that a program has potentially
recursive routines.
X • ••••
0031 An unsupported instruction
reference was detected.
X • ••••
0032 A sequencer length/position
parameter points past the end of
a data file.
X • ••••
0033 The length of LFU, LFL, FFU, FFL,
BSL, or BSR instruction points
past the end of a data file.
X • ••••
0034 A negative value for a timer
accumulator or preset value was
detected.
X • ••••
Fixed processors with 24 VDC
inputs only: A negative or zero
HSC preset was detected in a
HSC instruction.
X•
0035 TND, SVC, or REF instruction is
called within an interrupting or
user fault routine.
X••••
0036 An invalid value is being used
for a PID instruction parameter.
X••••
0038 A RET instruction was detected
in a non-subroutine file.
X • ••••
xx39 Invalid string length was
detected in a string file.
(xx = data file number)
X•••
003A An attempted write to a
constant data file.
•••
003B Motherboard and Daughter Card
firmware do not match.
•
003C STI watchdog time-out. •••
003D J4 jumper in wrong position. ••
005F Invalid Rack ID •••
xx50 A chassis data error is detected.
(xx = slot number)
X • ••••
