Publication 1747-RM001G-EN-P - November 2008
B-60 SLC Status File
The following table lists all combination settings for S:1/10, S:1/11 and
S:1/12.
Table B.5 Combination Settings for S:1/10, S:1/11, and S:1/12
S:1/10 S:1/11 S:1/12 Memory
Module
Present?
SLC
Memory
Error?
Memory
Module
Transfer?
Mode Before/After Powerdown Major Fault
Before/After
Powerdown
0 0 0 don’t care N/A no don’t care/same don’t care/same
100no N/Ano (REM) PROG/(REM) PROG dont’ care/same
REM RUN/faulted REM PROG no fault/faulted
RUN/faulted RUN
yes no no don’t care/same don’t care/same
yes yes yes faulted PROG/PROG faulted/no fault
faulted REM PROG/REM RUN
faulted RUN/RUN
010no N/Ano (REM) PROG/(REM) PROG don’t care/same
REM RUN/faulted REM PROG no fault/faulted
RUN/faulted RUN
yes N/A yes don’t care/same don’t care/no fault
001no N/Ano (REM) PROG/(REM) PROG don’t care/same
(REM) RUN/(REM) RUN
yes N/A yes PROG/PROG don’t care/no fault
REM PROG/REM RUN
(REM) RUN/(REM) RUN
011no N/Ano (REM) PROG/(REM) PROG don’t care/same
REM RUN/faulted REM PROG no fault/faulted
RUN/faulted RUN
yes N/A yes PROG/PROG don’t care/no fault
REM PROG/REM RUN
(REM) RUN/(REM) RUN
