Memory Usage C-3
NEG 1.50 Negate Data Handling 5-24
NEQ 1.50 Not Equal Comparison 3-2
NOT 1.00 Not Data Handling 5-23
OR 1.50 Or Data Handling 5-21
OSR 1.00 One-shot Rising Basic 2-5
OTE 0.75 Output Energize Basic 2-4
OTL 0.75 Output Latch Basic 2-4
OTU 0.75 Output Unlatch Basic 2-4
RES 1.00 Reset Basic 2-20
RET 0.50 Return from Subroutine Program Flow Control 6-3
RTO 1.00 Retentive Timer Basic 2-11
SBR 0.50 Subroutine Program Flow Control 6-3
SQC 2.00 Sequencer Compare Application Specific 7-6
SQO 2.00 Sequencer Output Application Specific 7-6
SUB 1.50 Subtract Math 4-5
SUS 1.50 Suspend Program Flow Control 6-8
TND 0.50 Temporary End Program Flow Control 6-7
TOD 1.00 Convert to BCD Data Handling 5-2
TOF 1.00 Timer Off-delay Basic 2-10
TON 1.00 Timer On-delay Basic 2-9
XIC 1.00 Examine If Closed Basic 2-3
XIO 1.00 Examine If Open Basic 2-3
XOR 1.50 Exclusive Or Data Handling 5-22
Table C.2 SLC 500 Fixed and SLC 5/01 List of Instructions (Continued)
Mnemonic Memory Usage
(user words)
Name Instruction Type Page
