Allen-Bradley SLC 500 Series - Page 588

Publication 1747-RM001G-EN-P - November 2008
C-8 Memory Usage
LIM 1.50 Limit Test Comparison 3-5
LFL 1.50 LIFO Load Data Handling 5-28
LFU 1.50 LIFO Unload Data Handling 5-28
MCR 0.50 Master Control Reset Program Flow Control 6-6
MEQ
(1)
1.50 Masked Comparison for Equal Comparison 3-4
MOV 1.50 Move Data Handling 5-17
MSG 34.75 Message Communication 12-5
MUL 1.50 Multiply Math 4-8
MVM 1.50 Masked Move Data Handling 5-18
NEG 1.50 Negate Data Handling 5-24
NEQ
(1)
1.50 Not Equal Comparison 3-2
NOT 1.00 Not Data Handling 5-23
OR 1.50 Or Data Handling 5-21
OSR 1.00 One-shot Rising Basic 2-5
OTE 0.75 Output Energize Basic 2-4
OTL 0.75 Output Latch Basic 2-4
OTU 0.75 Output Unlatch Basic 2-4
PID 23.25 Proportional Derivative PID 9-3
REF 0.50 Refresh Program Flow Control 6-10
RES 1.00 Reset Basic 2-20
RET 0.50 Return from Subroutine Program Flow Control 6-3
RPI 1.25 Reset Pending Interrupt Interrupt 11-34
RTO 1.00 Retentive Timer Basic 2-11
SBR 0.50 Subroutine Program Flow Control 6-3
SCL 1.75 Scale Data Math 4-15
SQC 2.00 Sequencer Compare Application Specific 7-6
SQL 2.00 Sequencer Load Application Specific 7-12
SQO 2.00 Sequencer Output Application Specific 7-6
SQR 1.25 Square Root Math 4-12
STD 0.50 Selectable Timer Interrupt Disable Interrupt 11-16
STE 0.50 Selectable Timer Interrupt Enable Interrupt 11-16
STS 1.25 Selectable Timer Interrupt Start Interrupt 11-17
SUB 1.50 Subtract Math 4-5
SUS 1.50 Suspend Program Flow Control 6-8
SVC Service Comms Communication 12-3
Table C.3 SLC 5/02 List of Instructions (Continued)
Mnemonic Memory Usage
(user words)
Name Instruction Type Page
