C-14 Memory Usage
ACL • • • • 2.00 ASCII Clear Receive and/or Send
Buffer
ASCII 10-9
ACN • • • • 3.00 String Concatenate ASCII 10-11
ACS • • • 2.00 Arc Cosine Math 4-29
ADD • • • • • 3.00, 4.00 Add Math 4-5
ADD FP • • • 4.00 Add Math 4-5
AEX • • • • 4.00 String Extract ASCII 10-12
AHL • • • • 4.00 ASCII Handshake Lines ASCII 10-13
AIC • • • • 2.00 Integer to String ASCII 10-14
AND • • • • • 3.00 And Data Handling 5-20
ARD • • • • 3.00 ASCII Read Characters ASCII 10-15
ARL • • • • 3.00 ASCII Read Line ASCII 10-17
ASC • • • • 4.00 String Search ASCII 10-18
ASN FP • • • 2.00 Arc Sine Math 4-29
ASR • • • • 3.00 ASCII String Compare ASCII 10-19
ATN FP • • • 2.00 Arc Tangent Math 4-30
AWA • • • • 3.00 ASCII Write with Append ASCII 10-20
AWT • • • • 3.00 ASCII Write ASCII 10-22
BSL • • • • • 3.00 Bit Shift Left Application Specific 7-4
BSR • • • • • 3.00 Bit Shift Right Application Specific 7-4
BTR • • 5.00 Block Transfer Read Block Transfer 8-1
BTW • • 5.00 Block Transfer Write Block Transfer 8-1
CEM • 73.00 ControlNet Explicit Message Communication 12-45
CLR • • • • • 3.00, 1.00 Clear Math 4-12
CLR FP • • • 1.00 Clear Math 4-12
COP • • • • • 3.00 File Copy Data Handling 5-13
COS FP • • • 2.00 Cosine Math 4-30
CPT • • •
(1)
Compute Math 4-25
CTD • • • • • 1.00 Count Down Basic 2-14
CTU • • • • • 1.00 Count Up Basic 2-13
Table C.5 SLC 5/03, SLC 5/04 and SLC 5/05 List of Instructions (Continued)
Mnemonic
FP = floating
point
Applies to SLC Memory Usage
(user words)
Name Instruction Type Page
OS300 OS301, OS400 OS302, OS401, OS501 OS302, OS401, OS501 Series C OS302, OS401, OS501 Series C, FRN 10+
