Allen-Bradley SLC 500 Series - Page 595

Publication 1747-RM001G-EN-P - November 2008
Memory Usage C-15
DCD • • • • • 2.00 Decode 4 to 1 of 16 Data Handling 5-10
DDV • • • • 2.00 Double Divide Math 4-11
DDT • • 6.00 Diagnostic Detect Application Specific 7-18
DEG FP • • • 2.00 Degree Data Handling 5-8
DEM • 74.00 DeviceNet Explicit Message Communication 12-52
DIV • • • • • 3.00, 4.00 Divide Math 4-9
DIV FP • • • 4.00 Divide Math 4-9
EEM • 64.00 Ethernet/IP Explicit Message Communication 12-58
ENC • • 2.00 Encode 1 of 16 to 4 Data Handling 5-11
EQU • • • • • 3.00 Equal Comparison 3-2
EQU FP • • • • 3.00 Equal Comparison 3-2
FBC • • 6.00 File Bit Comparison Application Specific 7-18
FFL • • • • • 3.00 FIFO Load Data Handling 5-26
FFU • • • • • 4.00 FIFO Unload Data Handling 5-26
FLL • • • • • 3.00 Fill File Data Handling 5-13
FRD • • • • • 2.00 Convert from BCD Data Handling 5-5
GEQ • • • • • 3.00 Greater Than or Equal Comparison 3-4
GEQ FP • • • • 3.00 Greater Than or Equal Comparison 3-4
GRT • • • • • 3.00 Greater Than Comparison 3-3
GRT FP • • • • 3.00 Greater Than Comparison 3-3
IID • • • • • 2.00 I/O Interrupt Disable Interrupt 11-32
IIE • • • • • 2.00 I/O Interrupt Enable Interrupt 11-32
IIM • • • • • 6.00 Immediate Input with Mask Program Flow Control 6-8
INT • • • • • 1.00 Interrupt Subroutine Interrupt 11-34
IOM • • • • • 6.00 Immediate Output with Mask Program Flow Control 6-9
JMP • • • • • 1.00 Jump to Label Program Flow Control 6-2
JSR • • • • • 1.00 Jump to Subroutine Program Flow Control 6-3
LBL • • • • • 2.00 Label Program Flow Control 6-2
LEQ • • • • • 3.00 Less Than or Equal Comparison 3-3
Table C.5 SLC 5/03, SLC 5/04 and SLC 5/05 List of Instructions (Continued)
Mnemonic
FP = floating
point
Applies to SLC Memory Usage
(user words)
Name Instruction Type Page
OS300 OS301, OS400 OS302, OS401, OS501 OS302, OS401, OS501 Series C OS302, OS401, OS501 Series C, FRN 10+
