Allen-Bradley SLC 500 Series - Page 596

Publication 1747-RM001G-EN-P - November 2008
C-16 Memory Usage
LEQ FP • • • • 3.00 Less Than or Equal Comparison 3-3
LES • • • • • 3.00 Less Than Comparison 3-3
LES FP • • • • 3.00 Less Than Comparison 3-3
LFL • • • • • 3.00 LIFO Load Data Handling 5-28
LFU • • • • • 3.00 LIFO Unload Data Handling 5-28
LIM • • • • • 1.00 Limit Test Comparison 3-5
LIM FP • • • • 1.00 Limit Test Comparison 3-5
LN FP • • • 2.00 Natural Log Math 4-31
LOG FP • • • 2.00 Log to the Base 10 Math 4-31
MCR • • • • • 1.00 Master Control Reset Program Flow Control 6-6
MEQ • • • • • 4.00 Masked Comparison for Equal Comparison 3-4
MOV • • • • • 2.00 Move Data Handling 5-17
MOV FP • • • • 2.00 Move Data Handling 5-17
MSG • • • • • 20.00 Message Communication 12-5
MUL • • • • • 3.00 Multiply Math 4-8
MUL FP • • • 3.00 Multiply Math 4-8
MVM • • • • • 3.00, 4.00 Masked Move Data Handling 5-18
NEG • • • • • 3.00 Negate Data Handling 5-24
NEG FP • • • 3.00 Negate Data Handling 5-24
NEQ • • • • • 3.00 Not Equal Comparison 3-2
NEQ FP • • • • 3.00 Not Equal Comparison 3-2
NOT • • • • • 3.00 Not Data Handling 5-23
OR • • • • • 3.00 Or Data Handling 5-21
OTE • • • • • 1.00 Output Energize Basic 2-4
OTL • • • • • 1.00 Output Latch Basic 2-4
OTU • • • • • 1.00 Output Unlatch Basic 2-4
PID • • • • • 26.00 Proportional Integral Derivative PID 9-1
RAD FP • • • 2.00 Radian Data Handling 5-9
REF • • • • • 1.00 I/O Refresh Program Flow Control 6-10
Table C.5 SLC 5/03, SLC 5/04 and SLC 5/05 List of Instructions (Continued)
Mnemonic
FP = floating
point
Applies to SLC Memory Usage
(user words)
Name Instruction Type Page
OS300 OS301, OS400 OS302, OS401, OS501 OS302, OS401, OS501 Series C OS302, OS401, OS501 Series C, FRN 10+
