Publication 1747-RM001G-EN-P - November 2008
Memory Usage C-17
RES • • • • • 1.00 Reset Basic 2-20
RET • • • • • 1.00 Return from Subroutine Program Flow Control 6-3
RHC • • 2.00 Read High Speed Clock Application Specific 7-17
RMP ••2.00 Ramp Math 4-20
RPC • 3.00 Read Program Checksum Application Specific 7-23
RPI • • • • • 2.00 Reset Pending Interrupt Interrupt 11-34
RTO • • • • • 1.00 Retentive Timer Basic 2-11
SBR • • • • • 1.00 Subroutine Program Flow Control 6-3
SCL FP • • • 4.00 Scale Data Math 4-15
SCP • • • 6.00 Scale with Parameters Math 4-13
SCP FP • • • 6.00 Scale with Parameters Math 4-13
SIN FP •••2.00 Sine Math 4-32
SQC • • • • • 5.00 Sequencer Compare Application Specific 7-6
SQL • • • • • 4.00 Sequencer Load Application Specific 7-12
SQO • • • • • 5.00 Sequencer Output Application Specific 7-6
SQR • • • • • 2.00, 3.00 Square Root Math 4-12
SQR FP • • • 3.00 Square Root Math 4-12
STD • • • • • 1.00 Selectable Timer Interrupt Disable Interrupt 11-16
STE • • • • • 1.00 Selectable Timer Interrupt Enable Interrupt 11-16
STS • • • • • 3.00 Selectable Timer Interrupt Start Interrupt 11-17
SUB • • • • • 3.00 Subtract Math 4-5
SUB FP • • • 4.00 Subtract Math 4-5
SUS • • • • • 2.00 Suspend Program Flow Control 6-8
SVC • • • • • 1.00 Service Communication Communication 12-3
SWP •••2.00 SWAP Math 4-28
TAN FP • • • 2.00 Tangent Math 4-32
TDF • • 3.00 Compute Time Difference Application Specific 7-17
TND • • • • • 1.00 Temporary End Program Flow Control 6-7
TOD • • • • • 2.00 Convert to BCD Data Handling 5-2
Table C.5 SLC 5/03, SLC 5/04 and SLC 5/05 List of Instructions (Continued)
Mnemonic
FP = floating
point
Applies to SLC Memory Usage
(user words)
Name Instruction Type Page
OS300 OS301, OS400 OS302, OS401, OS501 OS302, OS401, OS501 Series C OS302, OS401, OS501 Series C, FRN 10+
